Product overview
The TMT multipoint thermocouple is applicable to measuring multiple locations or multiple measurements of position when the temperature gradient of the production field isn't significant. It's widely used for large fertilizer synthetic tower and storage tank.
Product model selection
Multi-point armoured element thermocouple with fixed device
Model | Graduation number | Measuring range ℃ | Number of measuring points | Protective tube material |
TMT-K3310 | K | 0~1000 | 2~12 | GH300 |
0~800 | 1Cr18Ni9Ti | |||
TMT-E2210 | E | 0~600 | 1Cr18Ni9Ti | |
TMT-K6100 | K | 0~1000 | GH3030 | |
0~800 | 1Cr18Ni9T | |||
TMT-E5800 | E | 0~600 | 1Cr18Ni9Ti |
Multiple pair armoured element thermocouple without fixed device
Name | Model | Graduation number | Working end form |
Nickel-chromium-constantan Multiple pair armoured element thermocouple | TMT -1315 -1313 -1314 -1316 | E | Insulating type |
TMT -1324 -1323 -1325 -1326 | Body contact type | ||
Nickel-chromium-nisiloy Multiple pair armoured element thermocouple
| TMT -1314 -1313 -1315 -1316 | K | Insulating type |
1W1 -1324 -1323 -1325 -1326 | Body contact type |
Thermocouple temperature sensing element (multiple pair thermocouple temperature sensing element)
Thermocouple | Model | Graduation number | Temperature measurement range ℃ | Specification |
Total length mm | ||||
Nickel-chromium-nisiloy | TMT-K100 | K | 0~800 | Customization by the user |
Nickel-chromium-copper nickel | TMT-E100 | E | 0~600 | |
Nickel-chromium-nisiloy | TMT-K200 | K | 0-800 | <10000 |
Nickel-chromium-copper nickel | TMT-E200 | E | 0~600 |
